HOT SELLING PRODUCTSTD2230
Due to Inflation Worldwide there may be a change in Price. Please Call Us for Price Confirmation and Stock Availability.
|
|
In Stock
Call for Price
(+971 72091222)
FREE SHIPPING
SECURE CHECKOUT
EASY RETURNS
UAE BASED SUPPORT TEAM
GUARANTEED SAFE CHECKOUT
Audio
Built-in speaker(s)
Yes
RMS rated power
6 W
Performance
Built-in speaker(s)
Yes
RMS rated power
6 W
Built-in microphone
No
Built-in camera
No
AMD FreeSync
No
NVIDIA G-SYNC
No
Windows operating systems supported
Windows 10, Windows 7, Windows 8, Windows 8.1
Mac operating systems supported
Yes
Linux operating systems supported
Yes
Other operating systems supported
Android
Display
Screen shape
Flat
Maximum refresh rate
76 Hz
HD type
Full HD
Display technology
LCD
Contrast ratio (dynamic)
50000000:1
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Pixel pitch
0.24825 x 0.24825 mm
Horizontal scan range
24 - 82 kHz
Vertical scan range
50 - 76 Hz
Supported graphics resolutions
640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Display resolution
1920 x 1080 pixels
Response time
5 ms
Display diagonal
54.6 cm (21.5")
Contrast ratio (typical)
1000:1
Touchscreen type
Multi-user
Touchscreen
Yes
Number of simultaneous touchpoints
10
Panel type
ADS
Display diagonal (metric)
54.6 cm
Touch technology
Multi-touch
Touchscreen technology
Projected capacitive system
Display brightness
250 cd/m²
Management features
On Screen Display (OSD)
Yes
Number of OSD languages
12
Multimedia
Number of speakers
2
Built-in speaker(s)
Yes
RMS rated power
6 W
Built-in microphone
No
Built-in camera
No
Design
Certification
cULus, FCC-B, ICES003, Energy Star 8.0, EPEAT Bronze, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BIS, CCC, China RoHS, China Energy Label, CECP
Product colour
Black
Camera
Built-in camera
No
Ports & interfaces
Built-in USB hub
Yes
USB hub version
3.2 Gen 1 (3.1 Gen 1)
USB upstream port type
USB Type-B
Number of upstream ports
1
USB Type-A downstream ports quantity
2
HDMI ports quantity
1
DisplayPorts quantity
1
Audio input
1
Audio output
1
HDMI
Yes
HDMI version
1.4
DisplayPort version
1.2
Number of USB Type-B upstream ports quantity
1
Technical details
HDMI
Yes
Display viewable area (HxV)
476.64 x 268.11 mm
Built-in microphone
No
Product colour
Black
Sustainability certificates
EPEAT Bronze, ErP
Compliance certificates
CE, REACH, RoHS
Power supply type
AC
Weight (with stand)
3.58 kg
Touchscreen type
Multi-user
Touchscreen
Yes
Number of simultaneous touchpoints
10
Software
Windows operating systems supported
Windows 10, Windows 7, Windows 8, Windows 8.1
Mac operating systems supported
Yes
Linux operating systems supported
Yes
Ergonomics
Wall mountable
Yes
VESA mounting
Yes
Panel mounting interface
100 x 100 mm
Tilt angle range
20 - 70°
On Screen Display (OSD)
Yes
Number of OSD languages
12
Tilt adjustment
Yes
Power
Power supply type
AC
AC input voltage
100-240 V
AC input frequency
50 - 60 Hz
Power consumption (typical)
25 W
Energy efficiency class (SDR)
F
Energy consumption (SDR) per 1000 hours
19 kWh
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
20 - 90%
Storage relative humidity (H-H)
5 - 90%
Packaging content
Cables included
AC, Audio (3.5mm), HDMI, USB
Weight & dimensions
Width (with stand)
490 mm
Depth (with stand)
47 mm
Height (with stand)
299 mm
Weight (with stand)
3.58 kg
Package width
550 mm
Package depth
114 mm
Package height
371 mm
Package weight
4.7 kg
Packaging data
Package width
550 mm
Package depth
114 mm
Package height
371 mm
Package weight
4.7 kg
Cables included
AC, Audio (3.5mm), HDMI, USB
Sustainability
Sustainability certificates
EPEAT Bronze, ErP
European Product Registry for Energy Labelling (EPREL) code
389769
Logistics data
Harmonized System (HS) code
85285210
Other features
HDMI
Yes
Power supply type
AC
Display viewable area (HxV)
476.64 x 268.11 mm
Touchscreen type
Multi-user
Touchscreen
Yes
Number of simultaneous touchpoints
10
Certificates
Certification
cULus, FCC-B, ICES003, Energy Star 8.0, EPEAT Bronze, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BIS, CCC, China RoHS, China Energy Label, CECP
TD2230
